Abrasives: Grinding Discs for Angle Grinders
What is a grinding disc?
A grinding disc is an abrasive wheel that is very similar to a cutting disc. The main difference being they are usually considerably thicker.
For example, a typical 115MM diameter cutting disc is 1MM in thickness.A typical 115MM diameter grinding disc is 6MM in thickness. Cutting & grinding discs are made of the same materials. That being abrasive material, bonding resin & fibreglass.
What is a grinding disc used for?
Grinding discs are used to quickly remove large amounts of stock from metal. Whereas cutting discs are used to make a thin incision in metal. Stock removal is the process of removing metal from a workpiece. Grinding discs carry out this process in a prompt manner with minimal effort.
A common application for grinding discs is the removal of deficient welds so the workpiece can be re-welded.
Common Grinding Disc Diameters & Thickness'
The most common grinding discs are:
- 115MM (4.5 inch) x 6MM
- 115MM (4.5 inch) x 7MM
- 125MM (5 inch) x 6MM
- 125MM (5 inch) x 7MM
- 150MM (6 inch) x 6MM
- 150MM (6 inch) x 7MM
- 178MM (7 inch) x 6MM
- 178MM (7 inch) x 7MM
- 230MM x (9 inch) x 6MM
- 230MM x (9 inch) x 7MM
Some larger diameter grinding discs (178MM and over) can be purchased in an 8MM thickness for extended lifespan.
Which materials can I grind?
As with cutting discs all materials can be ground. However, all materials have their own idiosyncrasies. For instance, aluminium can very quickly clog a grinding disc. Stainless steel can be very hard waring on grinding discs which results in decreased life span.
