Miller Migmatic 320i MIG Welder - 3 Phase

Availability: In stock
SKU
059015053
£2,774.00 £2,311.67
Availability
5-7 Working Days
dividebuy-logoCheck your eligibility

Fast check - won't affect your credit rating.

Delivery & Return

Free Delivery

For orders over £75

Interest Free Finance

Up to 10 months

Payment Secured

Safe shopping with us

Key Features

  • 15MM maximum weld thickness on mild steel
  • 30A - 300A output
  • Made in Italy
  • 400V input supply
  • Digital display
  • Duty cycle - 35% @ 320A
  • Fully synergic MIG control
  • 3 year warranty

Features

  • Digital meter - The Migmatic 320i is quipped with a digital display which shows all of your welding parameters
  • Fully synergic control - Control your parameters by setting your material type, wire diameter & material thickness
  • Adjustable Run- In and Burnback allows the user to optimise arc starts & stops, reducing wire stubbing or wire burning back onto the contact tip.
  • Thermal Protection with indicator light. Prevents damage when there is a risk of overheating, due to over duty cycle or reduced airflow.
  • 2-4 Step trigger mode with gas preflow and post flow function in 4 step mode.
  • Professional 4 roll driven wire drive.
  • Synergic control with programs for steel, stainless, aluminium and Mig Brazing.
  • Superior welding characteristics - Due to the modern transformer design, excellent starting and a very stable welding arc.

Technical Specifications

  • Input Power - 400V 3 Phase
  • Rated Output - 320A @ 35% Duty cycle
  • Voltage Range - 13V - 35V
  • Wire Speed - 1.5M / Min -  20M/ Min
  • Wire Diameter - 0.6MM - 1.2MM
  • IP Rating - IP23S
  • Max open circuit voltage - 70 VDC
  • Dimensions - H: 830MM W: 470MM D: 1070MM
  • Weight - 57KG

Includes Genuine Binzel Torch & Regulator

More Information
Brand Miller
GYS Offer No
Lead Time 5-7 Working Days
Is Laser Product No
Max Weldable Thickness 3MM, 5MM, 8MM, 10MM, 12MM
Input Voltage 400V
Warranty Period 3 Year
Max Wire Reel Capacity 15KG
Short Description

Key Features

  • 15MM maximum weld thickness on mild steel
  • 30A - 300A output
  • Made in Italy
  • 400V input supply
  • Digital display
  • Duty cycle - 35% @ 320A
  • Fully synergic MIG control
  • 3 year warranty
POA No
